TB Series adopts customized BEYMA HF driver with 1.75” voice coil, composite membrane and unique driver protection circuit, and customized Feiyun LF driver with 2” voice coil. The drivers are with advanced cooling system.


HF horn is made of DMF composite material to ensure very warm and dynamic sound. The coverage angle is (H°×V°) 90°×60° and the horn is 90° rotatable. This ensures accurate coverage no matter in vertical or horizontal direction.


15 years experienced Smart crossover technology, American Benelec XPP audio capacitor, iron-core inductor, customized metal resistor and manually soldered fiber board ensure stability and consistency and zero consumption, even with very high dynamic sound pressure.


The cabinet is made of CNC made Russian birch plywood, and is tongue and groove assembly. The finish is emery spraying. Black and white cabinets are available. Customized color according to the RAL code is available. The hexagonal sound-through holes in grill increase the penetration rate of sound.

main feature

◆ Customized driver from BEYMA

◆ American Benelec XPP audio capacitor with stable quality, reliable performance

◆ Active/ Passive crossover & selectable BI-AMP function

◆ Manually soldered fiber board to ensure zero consumption even in very high dynamic

◆ Unique driver protection circuit and high-efficient cooling system of the driver

◆ DMF composite material HF horn design, coverage angle 90° rotatable

◆ Solid CNC cabinet made of original Russian birch plywood, exquisite outlook and waterproof enclosure

◆ Tongue and groove assembly, compact and seamless CNC cabinet design ensures low resonance

◆ Touring grade emery spraying

core technology
